Austin Office Building Existing-Condition Documentation

Reality IMT provided existing condition documentation for this office building totaling approximately 120,000 SF in Austin, Texas.

Facility Type

Office Building

Project Scale

120,000 SF

Primary Service

Existing Condition Documentation

Project Purpose

Design Coordination

Project Overview

Project Summary

Reality IMT performed on-site 3D laser scanning of approximately 112,000 square feet, including the building interior and exterior elevations. The field measurements were followed by point cloud registration into a single point-cloud environment with QA/QC before modeling began. The point-cloud data was then converted into 3D vector geometry with accurate dimensions and building geometry.

The client needed accurate existing-condition documentation for a large multi-level building. Based on the scope, they were preparing for design, renovation, planning, or coordination work and needed a dependable Revit model and drawing sheets rather than relying on outdated or incomplete building records.

Office Building 3D Scanning and Existing Condition Documentation

Client Need

Project Challenge

The building was fully occupied and access was granted for one day only with an option to extend. However, Reality IMT deployed three scanners to operate simultaneously and was able to scan the entire building within a single day. The client needed field-verified existing-condition documentation across a large building area, including both interior and exterior elements.

Access / Coordination

The building was fully occupied and access was granted for one day only. Three scanners were deployed simultaneously to capture the entire 120,000 SF building in a single day.

Technical Documentation

The project required comprehensive interior and exterior documentation across a large multi-level building, converted into a Revit v2022 LOD ~350 model with sheet-based deliverables.

Schedule / Business Constraint

The single-day access window demanded precise planning and simultaneous multi-scanner deployment to avoid the need for return visits and keep the project on schedule.

Project Details

Project Type

Existing Condition Documentation

Location

Austin, Texas

Primary Industry

Municipal / Public Sector

Facility / Asset Type

Office Building

Primary Service

As-Built Drawings & CAD

Supporting Services

3D Laser Scanning, Existing Condition Documentation, Revit Modeling, Scan-to-BIM

Project Purpose

Design Coordination, Renovation Planning, Facility Documentation

Deliverables

Revit Model
Floor Plan Sheets
Reflected Ceiling Plans
Roof Plan
Building Sections
Exterior Elevations

Approximate Scope

120,000 SF

Client

Municiple Government

Deliverables

Revit Model, CAD Drawings, PDF Drawing Sheets, Point Cloud

Reality IMT’s Approach

Single-Day Multi-Scanner Capture and Architect-Ready Deliverables

Reality IMT structured the work to capture a 120,000 SF occupied office building in a single day and convert the data into an architect-facing Revit deliverable for design and coordination.

Planning & Scope Alignment

A detailed single-day deployment plan was developed to coordinate three simultaneous scanners across the occupied office building, maximizing capture efficiency within the limited access window.

Field Capture

Three scanners operated simultaneously to capture the entire 120,000 SF building interior and exterior elevations within the single-day access window.

Processing & QA/QC

Laser scan data was registered into a single point-cloud environment and quality-checked before Revit modeling began, ensuring accurate dimensions and building geometry.

Deliverable Production

Revit v2022 LOD ~350 was developed with sheets for each floor plan, reflected ceiling plans, roof plan, two to three building sections, and exterior elevations — a strong architect-facing deliverable.

Project Outputs

Deliverables Provided

The deliverables below reflect the archived project information and should be matched with project-specific images before publication.

Revit Model

Revit v2022 LOD ~350 with accurate 3D vector geometry, dimensions, and building conditions for design coordination and renovation planning.

Floor Plan Sheets

Sheet-based floor plan documentation for each level, supporting interior planning, space allocation, and design coordination.

Reflected Ceiling Plans

RCP sheets documenting ceiling conditions, lighting, HVAC, and MEP elements for coordination with design and engineering teams.

Roof Plan

Documented roof geometry and conditions for mechanical coordination, waterproofing assessment, and renovation planning.

Building Sections

Two to three building sections showing floor-to-floor heights, structural relationships, and vertical building conditions.

Exterior Elevations

Measured exterior building elevations for facade assessment, signage planning, and design coordination.

Project Outcome

Field-Verified Revit Documentation for Design and Coordination

The completed documentation provided the client with a dependable Revit v2022 LOD ~350 model and comprehensive drawing sheets that replaced outdated or incomplete building records. The architect-facing deliverable supported design coordination, renovation planning, and facility documentation across the 120,000 SF office building.

The single-day, multi-scanner approach eliminated the need for extended access windows or return visits, keeping the project on schedule while minimizing disruption to occupied office operations.
